Double Coil Wires Mesh Welding Machine HW-WZD12

LAYOUTCharacteristics:Different diameter wires can be mounted on the wire payoffs at the same time, it can automat
CONTACT NOW
Double Coil Wires Mesh Welding Machine HW-WZD12 VIDEO
Features Related Products More Detail

Features of Double Coil Wires Mesh Welding Machine HW-WZD12

  • 1

    Different diameter wires can be mounted on the wire payoffs at the same time, it can automatically choose the wire in need.

  • 2

    For example, 6mm, 8mm,10mm,12mm wires are mounted on the four wire payoffs(line and cross wire payoff), different wires can be automatically changed in the wire automatically change the system, it's a huge time saving and lower cost.

  • 3

    Both line and cross wires are coils, no need pre-cut, more efficient and safer operation.

  • 4

    Cross wires can be dropped on the face side or the back side of the Cross wire discharging unit, no need to turn over the mesh for saving the space, no need to purchase the mesh turnover unit, it's a huge time and space saving, and lower cost.


Related Products Double Coil Wires Mesh Welding Machine HW-WZD12


  • Wire Mesh Welding Machine GWCP800T
    Technical Data of Wire Mesh Welding Machine GWCP800TMax Width2*160mmLine wire gap70mm-120mmCross wire gap≥100mmLine wire diameter8mm-12mm coilCross wire diameter6mm-8mm coilMax speed 40-60 strokes/mi... Wire Mesh Welding Machine GWCP800T
  • Wire Mesh Welding Machine GWC 2400/2800/3300
    Wire Mesh Welding Machine GWCZ2400/2800/3300 has advanced technology is introduced from Europe,lots of parts have patent for invention Wire Mesh Welding Machine GWC 2400/2800/3300
  • Double Coil Wires Mesh Welding Machine HW-WZD12
    LAYOUTCharacteristics:Different diameter wires can be mounted on the wire payoffs at the same time, it can automat Double Coil Wires Mesh Welding Machine HW-WZD12
  • Farming Wire Mesh Welding Machine GWCP1200XM-B
    High precision of PLC control,LCD display is easy for operating,have mighty graphics library,it is able to communicate with management software; Farming Wire Mesh Welding Machine GWCP1200XM-B
  • Wire Mesh Welding Machine GWC (P) 600-E
    Wire Mesh Welding Machine GWC(P)600-E has advanced technology is introduced from Europe,lots of parts have patent for invention,the high efficiency also high endurance and humane designs are safe and reliable; Wire Mesh Welding Machine GWC (P) 600-E
  • Wire Mesh Welding Machine GWCP 2400/2800/3300JZ-B
    Wire Mesh Welding Machine GWCP2400/2800/3300JZ-B has advanced technology is introduced from Europe,lots of parts have patent for invention,the high efficiency also high endurance and humane designs are safe and reliable Wire Mesh Welding Machine GWCP 2400/2800/3300JZ-B
  • Engineered Mesh Welding Line GWCAK3300
    Highly flexible and fully automatic welding line for the production of mesh sheets and reinforcing elements allowing processing different wire diameters and producing different openings No change-over times needed for the production of different sheet. Engineered Mesh Welding Line GWCAK3300
  • Wire Mesh Welding Machine GWCZ 2400/2600/2800/3300JZ-B
    Wire Mesh Welding Machine GWCZ2400 2800 3300JZ-B has advanced technology is introduced from Europe,lots of parts have patent for invention,the high efficiency also high endurance and humane designs are safe and reliable Wire Mesh Welding Machine GWCZ 2400/2600/2800/3300JZ-B

More Detail Double Coil Wires Mesh Welding Machine HW-WZD12

Characteristics of Double Coil Wires Mesh Welding Machine HW-WZD12

  • Different diameter wires can be mounted on the wire payoffs at the same time, it can automatically choose the wire in need.
  • For example, 6mm, 8mm,10mm,12mm wires are mounted on the four wire payoffs(line and cross wire payoff), different wires can be automatically changed in the wire automatically change the system, it's a huge time saving and lower cost.
  • Both line and cross wires are coils, no need pre-cut, more efficient and safer operation.
  • Cross wires can be dropped on the face side or the back side of the Cross wire discharging unit,  no need to turn over the mesh for saving the space, no need to purchase the mesh turnover unit, it's a huge time and space saving, and lower cost.

Technical Data of Double Coil Wires Mesh Welding Machine HW-WZD12


Working specifications:

Max. mesh width (cross wire length)

2,800 [mm]

Max. mesh length (line wire length)

6 [m]

Line wire spacing

100 [mm], freely adjustable

Cross wire spacing

50 - 400 [mm], The increment in multiples of 50 mm

Line wire diameter

Φ5 – Φ12 [mm] (off-coil)

Cross wire diameter

Φ5 – Φ12 [mm] (off-coil)

Max. welding capacity

Φ12 + Φ12 [mm]

Max. welding speed

80-120 [strokes/min] (cross wire no°/min)

Air consumption

≥0.6Mpa, 3.5m3/min

Cooling water consumption

≥0.2Mpa
