Wire Straightening and Cutting Machine 8-14Q

Wire Straightening and Cutting Machine GT8-14Q (wire cutting machines) fast in straightening and cutting: Our product could reach a highest straightening and cutting speed of 130m min, 3-4 times that of domestic similar products.
CONTACT NOW
Wire Straightening and Cutting Machine 8-14Q VIDEO
Features Related Products More Detail

Features of Wire Straightening and Cutting Machine 8-14Q

  • 1
    Wires can be automatically cut to length according to the input data;
  • 2
    Wires already be cut will be automatically aligned, it will save time and effort, advanced storage settings are being used;
  • 3
    Straightening process and conveying mechanism are controlled by CNC system, straightening speed and conveying speed can be step-less adjusted, little damage on steel surface; high straightening speed and straightness, high production and safety, instant braking;
  • 4
    A group of workers can operate two machines which are placed in positive and negative side, overall size small, increased production efficiency;
  • 5
    Servo motor cutting technology being used, timing belt drive, high accuracy positioning, no noise; workable with wire min length 800mm, stable quality, maintenance-free;

Related Products Wire Straightening and Cutting Machine 8-14Q


  • Wire Straightening and Cutting Machine GT1.8-3
    Wire Straightening and Cutting Machine GT1 8-3 fast in straightening and cutting: Our product could reach a highest straightening and cutting speed of 35m min, 3-4 times that of domestic similar products. Wire Straightening and Cutting Machine GT1.8-3
  • Wire Straightening and Cutting Machine GT5-12Q
    Wire Straightening and Cutting Machine GT5-12Q (wire straighteners) fast in straightening and cutting: Our product could reach a highest straightening and cutting speed of 130m min, 3-4 times that of domestic similar products. Wire Straightening and Cutting Machine GT5-12Q
  • Wire Straightening and Cutting Machine 8-14Q
    Wire Straightening and Cutting Machine GT8-14Q (wire cutting machines) fast in straightening and cutting: Our product could reach a highest straightening and cutting speed of 130m min, 3-4 times that of domestic similar products. Wire Straightening and Cutting Machine 8-14Q
  • Wire Straightening and Cutting Machine GT3-7
    Wire Straightening and Cutting Machine GT3-7(automatic wire cutter machine) fast in straightening and cutting: Our product could reach a highest straightening and cutting speed of 100m min, 3-4 times that of domestic similar products. Wire Straightening and Cutting Machine  GT3-7
  • Wire Straightening and Cutting Machine GT8-12
    Stable and reliable flying-shear shear ensures high production,all have passed continuous three hundred thousand times test which is high frequency and high working conditions. Wire Straightening and Cutting Machine GT8-12
  • Wire Straightening and Cutting Machine WGT12
    Roller straightening mechanism being used which ensures ribs damage being reduced by 50%, working noise reduced by 30%, dirt pollution reduced by 30%. Wire Straightening and Cutting Machine WGT12

More Detail Wire Straightening and Cutting Machine 8-14Q

Characteristics of Wire Straightening and Cutting Machine 8-14Q

  • Wire Straightening and Cutting Machine GT8-14Q (wire cutting machines) fast in straightening and cutting: Our product could reach a highest straightening and cutting speed of 130m/min, 3-4 times that of domestic similar products.
  • Wire Straightening and Cutting Machine GT8-14Q (wire cutting machines) Suitable for new 3rd-grade steel: The straightening performance of our products is unique, and suitable fo straightening and cutting cold rolled ribbed steel bar and new 3rd-grade steel which is promoted by the government.
  • Cutting Machine GT8-14Q (wire cutting machines) intelligent control: We adopt PLC to control. Operate, regulate and remote control, which is easy and reliable.

Technical Data of Wire Straightening and Cutting Machine 8-14Q

Raw material

Smooth and ribbed wires in coil (low carbon)

Production capacity

Φ8 – Φ14 [mm] (tensile strength≤335Mpa)

Φ8 – Φ12 [mm] (tensile strength≤400Mpa)

Maximum straightening speed

130 [m/min] (AC Frequency Convert Control)

Cutting length

800 – 12,000 [mm]

Cutting method

Servo motor

Length gauge

Manual

Linearity of straightening

≤2 [mm/m]

Tolerance of cut-to-length

≤±1 [mm]

Total power

56.5 [Kw]

Total weight

5,500 [Kg]

Overall dimension

23 × 2.6 × 1.7 [m] (L×W×H)
